Features:

• Output power capacity: 450 Watts / 800VA
• Output Connections: (6) IEC 60320 C13 (Battery Backup)
• Nominal Output Voltage: 230V
• Nominal Input Voltage: 230V
• Input Connections: IEC 60320 C14
• Cord Length: 1.5meters

APC Easy UPS, 800VA, Floor/Wall Mount, 230V, 6x IEC C13 outlets, AVR

Easy UPS provides power protection for unstable power conditions, ensuring consistent and reliable connectivity at the most critical moments.

• Automatic Voltage Regulation (AVR): Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment.
• Wall-mount holes: Allow flexibility for setup in tight locations and mounting on walls or other surfaces.

Safety:

• Safety-agency approved: Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Protection:

• Battery and surge-protected outlets: Back up and protect your hardware and data during power outages, surges, and spikes.
• Battery backup and surge protection: Outlets provide abundant runtime for network gateway equipment and other critical low-power devices, allowing for hours of internet access during a power outage.

Availability:

• Intelligent battery management: Maximizes battery performance, life, and reliability through intelligent, precision charging.
• Battery failure notification: Provides early-warning fault analysis on batteries enabling timely preventive maintenance.
• Advanced Safety Features: Safeguard your Home UPS from overloads, excessive mains voltages, short circuits, installation mishaps, and battery damage due to low voltage situations.

Manageability:

• LED Indicators: Provide easy-to-read status of the unit and utility power conditions.
• Audible alarms: Provides notification of changing utility power and UPS power conditions.

Features:

• Cold-start capable: Provides temporary battery power when the utility power is out.
• Boost Automatic Voltage Regulation (AVR): Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.
• Transformer-block spaced outlets: Protect equipment with input transformer blocks without blocking access to other receptacles.
• Sleek design: Slim, modern design can be upright, flat, or wall-mounted to comfortably fit any electronics set-up and complement home décor.

Specifications:

Output:

• Max Configurable Power (Watts): 450 Watts / 800VA
• Output Frequency (sync to mains): 50/60 Hz +/- 1 Hz Unsynchronised
• Topology: Line interactive
• Waveform type: Stepped approximation to a sinewave
• Transfer Time: 6 ms typical: 10 ms maximum

Input:

• Input frequency: 50/60 Hz +/- 5 Hz Auto-sensing
• Input voltage range for main operations: 170 - 280
• Number of Power Cords: 1

Batteries & Runtime:

• Battery type: Lead-acid battery
• Typical recharge time: 8hour(s)
• Nominal Battery Voltage: 12 V
• Expected Battery Life (years): 3 - 5

Surge Protection and Filtering:

• Surge energy rating: 156Joules

Physical:

• Maximum Height: 93MM, 9.25CM
• Maximum Width: 161MM, 16.05CM
• Maximum Depth: 305MM, 30.5CM
• Net Weight: 5.3KG
• Shipping weight: 5.6KG
• Shipping Height: 237MM, 23.7CM
• Shipping Width: 373MM, 37.3CM
• Shipping Depth: 143MM, 14.3CM
• Color: Black
• SCC Codes: 10731304338342

Environmental:

• Operating Temperature: 0 - 40 °C
• Operating Relative Humidity: 0 - 90 %
• Operating Elevation: 0 - 2032.1meters
• Storage Temperature: -20 - 50 °C
• Storage Relative Humidity: 0 - 90 %
• Storage Elevation: 0 - 15240meters
• Audible noise at 1 meter from the surface of the unit: 40.0dBA
• Protection Class: IP20

Conformance:

• Approvals: CE
• Standard warranty: 2 years repair or replace

Sustainable Offer Status:

RoHS: Compliant
