Specifications:

Processor:

• 12th Generation Intel® Core™ i3-12100 (12 MB cache, 4 core, 8 Threads, up to 4.30 GHz, 65 W)
• 12th Generation Intel® Core™ i5-12400 (18 MB cache, 6 core, 12 Threads, up to 4.40 GHz, 65 W)
• 12th Generation Intel® Core™ i5-12400F (18 MB cache, 6 core, 12 Threads, up to 4.40 GHz, 65 W)
• 12th Generation Intel® Core™ i5-12500 (18 MB cache, 6 core, 12 Threads, up to 4.60 GHz, 65 W)
• 12th Generation Intel® Core™ i7-12700 (25 MB cache, 12 core, 20 Threads, up to 4.90 GHz, 65 W)
• 12th Generation Intel® Core™ i7-12700F (25 MB cache, 12 core, 20 Threads, up to 4.90 GHz, 65 W)
• Intel® Pentium® Gold G7400 (6 MB cache, 2 core, 4 Threads, 3.70 GHz, 65 W)
• Intel® Celeron® G6900 (4 MB cache, 2 core, 2 Threads, 3.40 GHz, 65 W)

Operating System:

• Windows 11 Home, 64-bit
• Windows 11 Pro, 64-bit
• Windows 11 National Academic, 64-bit
• Ubuntu® 20.04 LTS, 64-bit

Graphics Card:

• Integrated: Intel® UHD Graphics
• Discrete: NVIDIA® GeForce® GT 730, 2 GB GDDR5
• NVIDIA® GeForce® GTX 1650 Super™, 4 GB GDDR6
• NVIDIA® GeForce® GTX 1660 Super™, 6 GB GDDR6

Memory:

• 4 GB, 1 x 4 GB, DDR4, 3200 MHz, UDIMM
• 8 GB, 1 x 8 GB, DDR4, 3200 MHz, UDIMM, dual-channel
• 8 GB, 2 x 4 GB, DDR4, 3200 MHz, UDIMM, dual-channel
• 16 GB, 2 x 8 GB, DDR4, 3200 MHz, UDIMM, dual-channel
• 16 GB, 1 x 16 GB, DDR4, 3200 MHz, UDIMM
• 32 GB, 2 x 16 GB, DDR4, 3200 MHz, UDIMM, dual-channel
• 32 GB, 1 x 32 GB, DDR4, 3200 MHz, UDIMM
• 64 GB, 2 x 32 GB, DDR4, 3200 MHz, UDIMM, dual-channel

Storage:

HDD:

• 3.5-inch, 1 TB, 7200 RPM, SATA, HDD
• 3.5-inch, 2 TB, 7200 RPM, SATA, HDD
• 2.5-inch, 1 TB, 7200 RPM, SATA, HDD
• 2.5-inch, 2 TB, 5400 RPM, SATA, HDD

SSD:

• M.2 2230, 256 GB, PCIe NVMe Gen3 x4, SSD, Class 35
• M.2 2230, 256 GB, PCIe NVMe Gen4 x4, SSD, Class 35
• M.2 2230, 512 GB, PCIe NVMe Gen3 x4, SSD, Class 35
• M.2 2230, 512 GB, PCIe NVMe Gen4 x4, SSD, Class 35
• M.2 2230, 1 TB, PCIe NVMe Gen3 x4, SSD, Class 35
• M.2 2230, 1 TB, PCIe NVMe Gen4 x4, SSD, Class 35
• M.2 2280, 512 GB, PCIe NVMe Gen4 x4, SSD, Class 40
• M.2 2280, 1 TB, PCIe NVMe Gen4 x4, SSD, Class 40
• M.2 2280, 512 GB, PCIe NVMe Gen3 x4, QLC NAND, Intel Optane SSD
• M.2 2280, 1 TB, PCIe NVMe Gen3 x4, QLC NAND, Intel Optane SSD

Ports: Front:

• 2 USB 3.2 Gen 1 ports
• 2 USB 2.0 ports
• 1 Global headset jack

Back:

• 2 USB 2.0 ports
• 2 USB 3.2 Gen 1 ports
• 1 Audio line-out port
• 1 HDMI 1.4b port
• HDMI 1.4 (Maximum resolution supported over HDMI is 1920x1200 @60Hz. No 4K/2K output)
• 1 DisplayPort 1.4
• 1 RJ-45 Ethernet port
• 1 AC power-supply port

Optical Drive:

• None
• Dell Slimline 16x DVD-RW drive

Slots - Vostro 3 TPM:

• 1 PCIe x16 slot
• 2 PCIe x1 slots
• 1 M.2 2230 slot for WiFi and Bluetooth combo card
• 1 M.2 2230/2280 slot for solid-state drive
• 2 SATA slots for 3.5-inch hard drive, 2.5-inch hard drive/solid-state drive
• 1 SATA slot for optical drive
• 1 PCI-32 x1

Slots - Vostro 3 non-TPM:

• 1 PCIe x16 slot
• 1 PCIe x1 slot
• 1 M.2 2230 slot for WiFi and Bluetooth combo card
• 1 M.2 2230/2280 slot for solid-state drive
• 2 SATA slots for 3.5-inch hard drive, 2.5-inch hard drive/solid-state drive
• 1 SATA slot for optical drive

Dimensions & Weight:

• Height: 12.77 in. (324.36 mm)
• Width: 6.06 in. (153.92 mm)
• Depth: 11.50 in. (292.10 mm)
• Starting weight: 11.13 lb (5.05 kg)

Chassis:

• Exterior Chassis Materials
  • Black with Silver mesh
  • Black with Sage Green mesh

Wireless:

• Realtek RTL8822CE, 2x2, 2.40 GHz/5 GHz, Wi-Fi 5 (WiFi 802.11ac), Bluetooth 5.0
• Intel® AX210, 2x2, 2.40 GHz/5 GHz/6 GHz, Wi-Fi 6E (WiFi 802.11ax), Bluetooth 5.2
• Intel® Wi-Fi 6 2x2 (Gig+), Bluetooth® wireless card

Power:

• 180 W Bronze internal Power Supply Unit (PSU)
• 240 W Bronze internal Power Supply Unit (PSU)
• 300 W Bronze internal Power Supply Unit (PSU)
